AirWave
60 GHz carrier-grade wireless backhaul for extreme distances, maximum throughput, and all-weather reliability.
AirWave is a 60 GHz carrier-grade wireless platform built for extreme-distance backhaul. Two hardware form factors — one ecosystem — engineered for wireless ISPs, enterprises, and carrier networks that cannot compromise on range or throughput.
Featuring IP67 weatherproofing, integrated GPS, multi-interface connectivity, and NDAA compliance, every AirWave unit is purpose-built for the demands of outdoor infrastructure at scale.
The Challenge
Connecting remote infrastructure over distances that fiber cannot reach — at carrier-grade speeds, in conditions that would ground conventional wireless.
AirWave was engineered to solve the last-mile and backhaul problem simultaneously: ultra-long PtP links to bring bandwidth into a region, and wide-sector multipoint distribution to put it to work across dozens of clients.
The AirWave platform operates across the 57–71 GHz spectrum worldwide. Adaptive modulation — 16QAM and QPSK — keeps links alive and optimized even as conditions change.
Precision engineering at every layer. AirOS runs on both units, providing a unified management interface, traffic shaping, site survey tools, and remote diagnostics across the entire deployment.
Integrated GPS on every unit delivers precise time synchronisation and location data — essential for carrier-grade network operations at any scale.
Aggregate Throughput
Max PtP Range
Antenna Gain (Ultra)
Simultaneous Clients (Beam)
Two products.
One platform.
AirWave Beam
60 GHz Point-to-Multipoint Base Station
Next-generation 60 GHz PtMP base station with 20 dBi sector antenna. 10 GbE + 10G SFP+ interfaces, integrated GPS, and AirOS management — purpose-built for carrier and enterprise outdoor networks.
AirWave Beam
60 GHz Point-to-Multipoint Base Station
Next-generation 60 GHz PtMP base station with 20 dBi sector antenna. 10 GbE + 10G SFP+ interfaces, integrated GPS, and AirOS management — purpose-built for carrier and enterprise outdoor networks.
Built for the field.
Ultra-Long-Range 60 GHz
46 dBi high-gain dish with adaptive 16QAM/QPSK modulation across 2160 MHz channels. 3.2 Gbps at distances up to 10 km.
90° Sector Coverage
AirWave Beam's wide sector antenna supports 32 simultaneous clients at up to 6 km — ideal for distribution in PtMP topologies.
Multi-Interface Backhaul
10 GbE RJ45, 10G SFP+, and 1G PoE Out ports give network architects flexible, high-capacity connectivity options on every unit.
Integrated GPS
Built-in GPS on every unit enables precise location data, accurate time synchronisation, and dedicated LED status indicators for field diagnostics.
All-Weather IP67
Aluminium alloy and UV-stabilised polycarbonate construction rated IP67. Operates at −40 to +60°C and withstands wind loads up to 200 km/h.
NDAA Compliant
WPA2-PSK (AES) encryption throughout. FCC, IC, and CE certified for North American and international carrier and enterprise deployments.
Wave BaseStation Comparison
WaveView NMS
A unified network management system purpose-built for AirWave deployments. Monitor every link, device, and alarm across your entire infrastructure from a single dashboard — in real time.
Live link status, throughput, and RSSI across all nodes
GPS-based device map with topology view
Alarm management and configurable thresholds
Firmware updates, configuration backup, and rollback
SNMP integration for existing NOC workflows
WavePlan
Link Planner
Design and validate AirWave deployments before a single unit ships. WavePlan models your RF environment, calculates link budgets, and predicts real-world performance across any terrain.
Interactive map-based link design tool
Automatic terrain and LOS analysis using elevation data
RF link budget calculator with Fresnel zone clearance
Predicted RSSI, throughput, and modulation per link
Exportable site survey reports for installation teams
